Introduction
(Area/Combo Alarms only)
Features:
• Digital LED readout of
system pressure signal
transmitted from sensor
module.
• Adjustable brightness of
digital LED readout.
• Individual LED’s indicate when system
pressure/vacuum is HIGH (red), LOW
(red), or NORMAL (green).
• Programmable high and low alarm
thresholds.
• Adjustable audible alarm mute duration.
• Individual high and low alarm dry-contact
relay outputs.
• Can transmit pressure or vacuum signal to
another digital display module for remote
applications.
(Area Alarms only)
Features:
• Monitors up to five
normally closed dry-
contact switch signals.
• Separate indicators for each of five signals
for normal (green) or abnormal (red)
conditions.
• Available (optional) with separate dry-
contact relay outputs for each of five
signals.
• Adjustable brightness of LED indicators.
Features:
• Reserves a space in
alarm panel for future
expansion.
• Used to fill unused alarm
panel module locations.
Alarm Modular Components (Cont.)
Blank Module
Multi-Signal Module
Digital Display Module
(Master/Combo Alarms only)
Features:
• Screw terminals for 32
dry-contact relay
outputs. Dry contacts
are normally-closed
when alarm panel is
powered.
• Relay contact ratings
are 2 A @ 30 VDC/0.5 A
@ 125 VAC
.
• Terminals accept 14 to
22 AWG wires.
Relay Board
