NOTE:
When an alarm panel is ordered with either local
or remote sensors, ALL sensors will either be
local or remote. Alarm panels with combination of
local and remote sensors are not available.
NOTE:
Alarm panel components in table on previous
page are listed in order of criticality. Unless other-
wise specified, most critical component will fill
position one, next less critical component will fill
position two, etc. etc.
234
1
123
45678
Area Alarms (Cont.)
Alarm Configurations (Cont.)
Introduction
Example: Model Number 6-TA2AR-OXAVWNBB
Example: Model Number 6-TA2AL-BOAV
Figure 10: Large Area Alarm
Figure 9: Small Area Alarm Panel
Figure 8: Large Area Alarm Front Panel
Figure 7: Small Area Alarm Front Panel
