QTERM-G72 Terminal Product Description
Qlarity-Based Terminal Hardware 85
SPEAKER
Standard Software programmable pitch and duration with audio (.wav) decoder
REAL-TIME CLOCK
Independent processor-based, real-time clock with battery backup, 1 second resolution
PHYSICAL
Configuration Panel-mount
Size 224 (W) x 154 (H) x 60 (D) mm
Weight 1 kg
Processor ARM926EJ-S 192 MHz
ENVIRONMENTAL
Sealing NEMA-4X front panel
Temperature
Operating: -20 to 70
°C
Storage: -30 to 85 °C
Humidity 5 to 95%, non-condensing
Vibration
10 to 1500 Hz, 4 g, 0.5 octave/minute sweep
5 to 500 Hz, 1.5 g RMS
Shock 40 g, 11 ms, common orthogonal axis
ESD
8 kV contact
15 kV air
POWER
10 to 32 VDC (See section 7.4.3 for current consumption)
SOFTWARE
Programming language Qlarity (object-based)
Design environment Qlarity Foundry (Windows)
Command line compiler Qlarify (Win32 or Linux)
CERTIFICATION
FCC Part 15, Class A
CE Certification EN-55022, EN-55024 and EN-60950
UL Listed
