Bernina 540 - Instruction for Adjusting the Feed Dog; Needle and Stitch Plate; Changing the Needle; Selecting the Needle in the User Interface

Sewing preparation
37
2.9 Instruction for adjusting the feed dog
> Touch the icon «Feed dog up/down».
> Raise or lower the feed dog according to the animation.
2.10 Needle and stitch plate
Changing the needle
> Raise the needle.
> Switch the machine off and disconnect it from the power supply system.
> Remove the presser foot.
> Loosen the fixing screw of the needle manually.
> Pull the needle down.
> Hold the new needle with the flat side to the back.
> Insert the needle as far as it will go.
> Tighten the fixing screw manually.
Selecting the needle in the User Interface
After having changed the needle, it can be checked whether or not it can be used in combination with the
selected stitch plate.
> Touch the icon «Stitch plate/Needle selection».
> Select the inserted needle.
Selecting the needle type and the needle size
Convenient memory function: To prevent a loss of information, the needle type and the needle size can be
saved additionally on the machine. The saved needle type and the saved needle size can be checked at any
time.
> Touch the icon «Stitch plate/Needle selection».
