Field Description
• ?%1# 2 )3*!: Data traffic excluded from
NAT.
NAT method
Only for Type of traffic = ## % )3*!
Select the NAT method for outgoing data traffic. The starting
point for choosing the NAT method is a NAT scenario in which
an "internal" source host has initiated an IP connection to an "ex-
ternal" destination host over the NAT interface, and in which an
internally valid source address and internally valid source port
are translated to an externally valid source address and an ex-
ternally valid source port.
Possible values:
• $11 % (UDP only): Any given external host may send IP
packets via the external address and the external port to the
initiating source address and the initial source port.
• % % (UDP only): Like full-cone NAT; as ex-
ternal host, however, only the initial "external" destination host
is allowed.
• + % % (UDP only): Like restricted-cone
NAT; however, exclusively data from the initial destination
port are allowed.
• (% (standard value) any protocol: Outbound, an ex-
ternally valid source address and an externally valid source
port are administratively set. Inbound, only response packets
within the existing connection are allowed.
In the NAT Configuration->Specify original traffic menu, you can configure for which
data traffic NAT is to be used.
Fields in the menu Specify original traffic
Field Description
Service Not for Type of traffic = ## % )3*! and NAT
method = $11 %, % % or +
% %.
Select one of the preconfigured services.
Possible values:
• . $ (default value)
bintec elmeg GmbH
11 Networking
bintec RS Series 213
