63
There are two tools to carry out the adjustment process: one to adjust the reagent rack and the other for the
pediatric rack.
In order to carry out this XYZ rack adjustment, you may use the screen or keyboard buttons. Movements using
keyboard:
- X axis movements: right and left cursor button
- Y axis movements: up and down cursor button
- Z axis movements: page up and page down button
Adjustment process using the tool
Place the tool as per the photograph.
Tools have been designed so that the square (pointed with arrows in the upper photograph) corresponds with
the position of the center of the well or bottle. And so that the tool lower level corresponds with the well or bottle
bottom.
Steps to follow:
1. Select the type of adjustment which you wish to carry out: adjustment of the tray (XYZ) of the pediatric
diameter rack or of the reagent rack.
2. Press the button Adjust.
