64
Service manual
3. Activate the option Adjust with the tool
4. Select the number of rack to start the adjustment process. By default, it starts with number 1.
5. Place the rack in the selected position, place the tool in the well 1 of the rack with and press Start.
6. Probe will automatically descend to a distance over the tool, in order to avoid colliding with it. If necessary,
move the probe with XY movements (screen or keyboard) to the center of the tool opening. Always press
Accept (although XY movements were not necessary)
7. The probe will descend some further steps through the tool opening.
From this position of approach, you may start the adjustment of values:
8. Move the probe just by X movements (screen or keyboard) until the probe touches the tool. When touching
the tool, this will make an acoustic warning. Press Accept X adjustment.
9. The new adjusted X value will appear in the upper table.
10. The probe will automatically come back to the center of the tool opening.
11. Move the probe just by Y movements (screen or keyboard) until it touches the tool. When touching the tool,
this will make an acoustic warning. Press Accept Y adjustment.
12. The new adjusted Y value will appear in the upper table.
13. The probe will automatically come back to the center of the tool opening and will descend some further
steps.
14. Move the probe just by Z movements (screen or keyboard) until it touches the tool lower part. This will make
an acoustic warning. Press Accept Z adjustment.
15. The new adjusted Z value will appear in the upper table.
16. The arm will automatically move to position 10 or 12, depending on the type of rack selected. Repeat steps
6 to 14.
17. Once the adjustments in position 10 or 12 are made, the arm is parked so the rack can move.
18. Place the rack in the following position of the tray, press Start. Repeat steps 6 to 14 to carry out the ad-
justments in the every position of the rack tray.
19. Once the adjustments are nished, they have to be kept in the instrument, so press Save.
Adjustment process without using tool
1. Select the type of adjustment which you wish to carry out: adjustment of the tray (XYZ) of the pediatric
diameter rack or of the reagent rack.
2. Press the button Adjust.
3. Deactivate the option Adjust with the tool
4. Select the number of rack to start the adjustment process. By default, it starts with number 1.
5. Place the rack in the selected position, place the well or bottle in well number 1 of the rack and press Start.
6. Probe will automatically descend to a distance over the well/bottle, in order to avoid colliding with it. Then,
probe has to be put into the well/bottle just a little. In order to do so:
- If probe is not centered in XY and out of the well or bottle opening: move the probe just by XY movements
(screen or keyboard) before carrying out Z movements to get the probe down.
- Then, get the probe slightly down with Z movements (screen or keyboard) just to make the adjustment
of the center easier.
From this position of approach, you may start the adjustment of values:
7. Adjust the well/bottle center: to do so, move the probe by X and Y movements (screen or keyboard)
8. Adjust the bottle or well bottom: to do so, move the probe by Z movements (screen or keyboard) until it
reaches the bottom. To check it: move the bottle/well up and down.
9. To nish the XYZ adjustment, press Accept.
10. The new adjusted XYZ values will appear in the upper table. (Nevertheless, they are not saved in the ins-
trument yet).
11. The arm will automatically move to position 10 or 12, depending on the type of rack selected. Repeat steps
6 to 9.
12. Once the adjustments in position 10 or 12 are carried out, the arm is parked so the rack can be moved.
13. Place the rack in the following position of the tray, press Start. Repeat steps 6 to 9 to carry out the adjustments
in the every position of the rack tray.
14. Once the adjustments are nished, adjustments have to be kept in the instrument, so press Save.
