Instruction manual GSP Maintenance
38107010002 en-US 67 / 92
The scale must be dry to avoid a force shunt during operation.
Blade cover
Hold blade cover at handle with your
right hand, tilt towards blade and fix into
position with the stud.
Fasten the catch behind the blade guard
ring with the left hand.
Fig.94: Blade cover
Product carriage
From the top, place support plate in
groove.
Screw into place with the grip on the
guide element.
Fig.95: Support plate GSP HD
