Maintenance Instruction manual GSP
68 / 92 38107010002 en-US
Product fixation device
On the operator side of the carriage (see
arrow), place product fixation device hor-
izontally into the guide shaft and push it
onto the guide shaft.
Fig.96: Product clamping GSP H
Fig.97: Product clamping GSP HD
Remnant holder plate
Insert the remnant holder plate in to the
pusher guard, taking the attachments
into account.
Fasten with handle.
Fig.98: Remnant holder plate
