18
Command Syntax LED:RCOe <Nrf+>
Parameters 0.001 1
Example LED:RCO 0.2
Query Syntax LED:RCO?
Query Response <NR2>
5.4
OCP Testing Commands
5.5 OCP[:STATe] <bool>
This command is used to set the OCP test status.
Command Syntax OCP[:STATe] <bool>
Parameters 0- 1- OFF- ON
Example OCP:ON
Query Syntax OCP[:STATe]?
Query Response 0- 1
5.6 OCP:ISTart <NRf+>
This command is used to set the start current of the OCP test.
Command Syntax OCP:ISTart <NRf+>
Parameters MIN MAX
Unit
A
Example OCP:IST 3
Query Syntax OCP:ISTart?
Query Response <NR2>
5.7 OCP:IEND <NRf+>
This command is used to set the OCP cut-o current.
Command Syntax OCP:IEND <NRf+>
Parameters MIN MAX
Unit
A
Example OCP:IEND 6
