BK Precision 8500B Series Programming Manual

52
12.31 Read status register
Byte Description
0 RV Reverse voltage
1 OV Over voltage
2 OC Over current
3 OP Over power
4 OT Over temperature
5 SV remote sense wires are disconnected
6 CC Constant current
7 CV Constant voltage
8 CW Constant power
9 CR Constant resistance
10 PASS Pass autotest
11 FAULT fail to pass autotest
12 COMPLET Complete autotest
12.32 Read the information of E-Load (rated max current, max voltage, min voltage, max power, max resistance, min resistance). (01H)
Byte Description
1 AAh
2 Address 0-31, 0XFF)
3 Command 01H
4-7 Rated max current (Low byte to High byte order)
8-11 Rated max voltage (Low byte to High byte order)
12-15 Rated min voltage (Low byte to High byte order)
16-19 Rated max power (Low byte to High byte order)
20-23 Rated max resistance (Low byte to High byte order)
24-25 Rated min resistance (Low byte to High byte order)
26 Checksum
12.33 Set/Read hardware OPP value (02H/03H)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command 02H/03H
4-7 OPP value (Low byte to High byte order)
8-25 Reserved
26 Checksum
