12.58 Set/Read the current lower limit in CV mode. (BAH/BBH)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command BAH/BBH
4-7 The current lower limit (Low byte to High byte order)
8-25 System reserve
26 Checksum
12.59 Set/Read the voltage upper limit in CW mode. (BCH/BDH)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command BCH/BDH
4-7 The voltage upper limit (Low byte to High byte order)
8-25 System reserve
26 Checksum
12.60 Set/Read the voltage lower limit in CW mode (BEH/BFH)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command BEH/BFH
4-7 The voltage lower limit (Low byte to High byte order)
8-25 System reserve
26 Checksum
12.61 Set/Read max input resistance setting of E-load. (C0H/C1H)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command (C0H/C1H
4-7 max input resistance value (Low byte to High byte order)
8-25 System reserve
26 Checksum
