BK Precision 8500B Series - 6.1.5 CR Mode

37
Command Syntax TIMing:LOAD:MODE <mode>
Parameters CURR- VOLT- POW- RES
Example TIM:LOAD:MODE CURR
Query Syntax TIMing:LOAD:MODE?
Query Response <mode>
Related Commands If is executed, the setting of this command does not take eect.
10.4 TIM:LOAD:SETT OFF
10.5 TIMing:LOAD:VALue
This command is used to set the load parameters for the Timing test.
Command Syntax TIMing:LOAD:VALue <Nrf+>
Parameters A / V / W / , depending on TIMing:LOAD:MODE
Example TIM:LOAD:VAL 1
Query Syntax TIMing:LOAD:VALue?
Query Response <NR2>
Related Commands If TIM:LOAD:SETT OFF is executed, the setting of this command does not take eect.
10.6 TIMing:TSTart:SOURce
This command sets the trigger source for starting the test.
Command Syntax TIMing:TSTart:SOURce <source>
Parameters VOLT- CURR- EXT
Example TIM:TST:SOUR VOLT
Query Syntax TIMing:TSTart:SOURce?
Query Response <source>
10.7 TIMing:TSTart:EDGE
This command is used to set the trigger edge of the start test.
Command Syntax TIMing:TSTart:EDGE <edge>
Parameters RISE- FALL
Example TIM:TST:EDGE RISE
Query Syntax TIMing:TSTart:EDGE?
Query Response <edge>
