BK Precision 8500B Series Programming Manual

45
12.7 Set/Read current value of CC mod. (2AH/2BH)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command 2AH/2BH
4 The lowest byte of current value
5 The lower byte of current value.
6 The higher byte of current value.
7 The highest byte of current value.
From 8 To 25 Reserved
27 Checksum
NOTE: Represent current by 4 bytes of Hex. Low byte to High byte order. For example: current is 3.0000AHex code
is 0X00007530NO. 4 bye is 0X30NO. 5 bye is 0X75NO. 6 bye is 0X00NO. 7 bye is 0X00
12.8 8. Set/Read voltage value of CV mode. 2CH/2DH
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command 2CH/2DH
4 The lowest byte of voltage value.
5 The lower byte of voltage value.
6 The higher byte of voltage value.
7 The highest byte of voltage value.
8-25 Reserved
26 Checksum
NOTE: Represent voltage by 4 bytes of Hex. Low byte to High byte order. For example :voltage is 16.000VHex code
is 0X00003EB04th byte 0XB0 5TH byte is 0X3E6th byte is 0X007th bytes 0X00
12.9 9. Set/Read watt value of CW mode 2EH/2FH
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command 2EH/2FH
4 The lowest byte of max power value
5 The lower byte of max power value
6 The higher byte of max power value
7 The highest byte of max power value
8 to 25 Reserved
26 Checksum
