61
12.66 Set/Read Short steps. (D2H/D3H)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command (D2H/D3H
4-5 Autotest short steps (Low byte to High byte order), if one step is set to short on mode, then this bit should be
set to 1
6-25 Reserved
26 Checksum
12.67 Set/Read Pause steps. ( D4H/D5H)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command (D4H/D5H
4-5 Autotest Pause steps (Low byte to High byte order), if one step need to pause, then this bit should be set to 1
6-25 Reserved
26 Checksum
12.68 Set/Read single-step on-load time of autotest mode. ( D6H/D7H)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command D6H/D7H
4 Step number
5-7 Single step on-load time (Low byte to High byte order)
8-25 Reserved
26 Checksum
12.69 Set/Read delay time of single-step in autotest mode. ( D8H/89H)
Byte Description
1 AAh
2 Address (0-31, 0XFF)
3 Command D8H/D9H
4 Step number
5-7 Single step delay time (Low byte to High byte order)
8-25 Reserved
26 Checksum
