Reference: JP1, JP2 and JP3
These jumpers are used to set the card address as shown below.
Reference:
JP2 and JP3
These jumpers control the address setting for the reader ports. JP2 configures addresses for
the first two reader ports, while JP3 configures addresses for the third and fourth readers.
Reference:
JP1
Jumper JP1 sets the addresses for the door contacts, request-to exit inputs and door strike
outputs.
Reference:
J1 and J2
These jumpers are not in used in the Access Easy Controller application. They are reserved for
future implementation.
4-reader board
Address
JP1 JP2 JP3
1 1-2 OUT 1-2 OUT 1-2 IN
3-4 OUT 3-4 OUT 3-4 OUT
5-6 OUT 5-6 OUT 5-6 OUT
2 1-2 IN 1-2 OUT 1-2 IN
3-4 OUT 3-4 IN 3-4 IN
5-6 OUT 5-6 OUT 5-6 OUT
3 1-2 OUT 1-2 OUT 1-2 IN
3-4 IN 3-4 OUT 3-4 OUT
5-6 OUT 5-6 IN 5-6 IN
4 1-2 IN 1-2 OUT 1-2 IN
3-4 IN 3-4 IN 3-4 IN
5-6 OUT 5-6 IN 5-6 IN
