3.3 Three Controller Systems
UL & FCC Version
System Type Max. Readers Max. Inputs Max. Outputs Access Easy Controller AEC 4W UPS 1 / AEC 8W UPS 1 4-reader board AEC 4W EXT 8-Input/8-Output Card AEC 8I8O EXT Converter Card AEC SER EXT Access Easy Extension AEC EXT UPS 1
System C120012- 11
System D160013- 11
System F88811111
System G128812111
System H168813111
System I 4 16 16 1 - 2 1 1
System J 8 16 16 1 1 2 1 1
System K 8 16 16 1 1 2 1 1
System M 8 24 24 1 1 3 1 1
System N 8 24 24 1 1 3 1 1
System Q 4 32 32 1 - 4 1 1
System Type Max. Readers Max. Inputs Max. Outputs Access Easy Controller AEC 4W UPS 2 / AEC 8W UPS 2 4-reader board AEC 4W EXT 8-Input/8-Output Card AEC 8I8O EXT Converter Card AEC SER EXT Access Easy Extension AEC EXT UPS 2
System L16323213422
System 012242412322
System p16242413322
System R 8 32 32 1 1 4 2 2
System S12323212422
System T16323213422
