Access Easy Controller System Layout | en 15
Bosch Security Systems Hardware Manual Ver 2.0.0 | 2006.07
CE Version (Not for UL Listed System)
3.4 Controller Specifications
Hardware Specifications
General
X Power Supply:
X Input Supply: 18 VAC (UL Listed System)
a. 230VAC (CE Listed System, using Power Supply Unit)
b. Battery backup: 12V, 7.0AH
c. Battery charging: Built-in charger
X Card Reader supported:
a. Basic controller supports 4 readers
b. Fully configured pane supports up to 16 readers
c. Strike Output Relays: Included on reader interface card.
d. Door Contact Inputs: Included on reader interface card.
e. Request-to-exit Inputs: Included on reader interface card.
X Reader Type: Any 2-wire Wiegand output reader. HID Proximity readers recommended.
The following readers have been verified by UL for compatibility with the controller :
a. HID MiniProx Reader
b. HID 20676 ProxPro with Keypad Reader
c. HID 20676 ProxPro without Keypad Reader
d. HID 20520 ProxPoint Reader
X Inputs: Maximum of 32. Both normally open and normally closed devices supported.
X Outputs: Maximum of 32 (From-C PCB mounted output control relays). Contact rating: 1
Amp @ 24 VDC.
X Dimensions of Access Easy Controller and Access Easy Extension :
H: 525mm x W: 455mm x D: 90mm
System Type Max. Readers Max. Inputs Max. Outputs Access Easy Controller AEC 4W UPS 1 / AEC 8W UPS 1 4-reader board AEC 4W EXT 8-Input/8-Output Card AEC 8I8O EXT Converter Card AEC SER EXT Access Easy Extension AEC EXT UPS 1
System L16323213422
System 012242412322
System p16242413322
System R8323211422
System S12323212422
System T16323213422
