Access Easy Controller 4-Reader Boards and 8 Input/8 Output Boards | en 105
Bosch Security Systems Hardware Manual Ver 2.0.0 | 2006.07
Reference: JP2
These jumpers are used to set the card address as shown following.
15.4 Reader & I/O Board Address Settings
The following diagrams shows the detailed drawing digram of 4 Reader Board and 8-Input/
Output Board and their jumper settings for each card.
8-Input/Output card board
Address
JP1
1 1-2 OUT
3-4 OUT
5-6 OUT
2 1-2 IN
3-4 OUT
5-6 OUT
3 1-2 OUT
3-4 IN
5-6 OUT
4 1-2 IN
3-4 IN
5-6 OUT
