Access Easy Controller Before You Begin | en 7
Bosch Security Systems Hardware Manual Ver 2.0.0 | 2006.07
1 Before You Begin
The Access Easy Controller Hardware Installation Manual contains detailed information and
connections diagrams about using the Access Easy Controller hardware and peripheral field
devices.
In this manual, we will use the following terminologies to describe the components and
peripheral field devices in the Access Easy Controller hardware manual, please take note of
the following terminologies.
Terminology Name
Access Easy Controller Access Easy Controller with CPU board, 4 wiegand interfaces/2x4
wiegand interfaces and door controls (8 IN/OUT), secure comm.
Board, Converter board, Power supply - Charger board. AC/DC con-
verter CE or AC/AC Transformer UL.
Access Easy Extension Access Easy Extension enclosure with Power supply - Charger
board, DC/DC Converter CE, AEC Extension Enclosure CE, AEC-EXT-
UPS1
4 Reader Board / Card Access Easy Extension 4 wiegand interfaces and door controls (8 IN/
OUT), fitting parts.
8 IN/OUT Board / Card Access Easy Extension 8 input and 8 output, fitting parts.
Converter Board /
Card
Access Easy Extension conversion serial RS485 to reader or IO
boards (1 for each enclosure).
CPU Board / Card Access Easy CPU Card.
Secure Comm. Card Access Easy Secure/Communication Card.
Power Supply Card Access Easy AC/DC Converter CE or AC/AC transformer UL.
Power Supply Access Easy Power supply - Charger CE / Charger UL.
EM Reader Access Reader 8000 Wiegand EM Prox.
S-Series Reader S-Series EM Prox / HID Prox / Mifare Prox
