56 en | How to Install & Set the TCP/IP Address on a PC Access Easy Controller
Ver 2.0.0 | 2006.07 Hardware Manual Bosch Security Systems
9 How to Install & Set the TCP/IP Address on a PC
In this section, the necessary steps are described to install the TCP/IP communication proto-
col on a computer and to assign an IP address to a computer. Two examples are given. The
first is for a computer running Windows 98. The second is for Apple Macintosh.
Network Configuration on a Windows Computer (Windows XP)
The example described here is based on Window XP. Slight differences will be noticed in
some dialog boxes, displays, and descriptions when the computer is configured with a differ-
ent version of the Windows operating system. Even with a different version of Windows, the
configuration principals are the same the steps are similar.
1. Click on the button, followed by Control Panel, Network Connections.
2. Double-click on the existing network connection icon and select Properties.
This will open the Network dialog box shown following.
