16 en | System Layout Access Easy Controller
Ver 2.0.0 | 2006.07 Hardware Manual Bosch Security Systems
CPU Card
X CPU type: 32-bit Microprocessor
X Type of Memory: 128 MB RAM, 32 MB Flash
X Ports:
a. 1 or 2 Ethernet Port
b. 2 RS-232 Port
c. 1 Parallel Port
Interface Cards
* Input Monitoring Points on the 4-reader board consists of door contact input and request-to-
exit inputs associated with reader controlled doors.
** Output Control Relays on the 4-reader board are the door strike/magnetic lock control
relays for the reader-controlled doors.
Operating Environment
Cards 4-Reader 8-Input/8-Output
Power Required 15VDC (from Power Sup-
ply Card)
15 VDC(from Power Sup-
ply Card)
Number of Wiegand Readers Sup-
ported
4-
Number of Input Monitoring Points 8* 8
Number of Output Control Relays 8** 8
Operating Temperature 0 to 50 deg. C
Humidity 10% to 95% non-condensing
Recommended Web Browsers: Microsoft Internet Explorer 4.0 and later, Netscape
Navigator 4.0 and later. (Netscape 6.0, 6.1 and 6.2
are not supported)
Number of Concurrent Logins: 8
Software Protection: Can create up to 25 individual user accounts, each
with password protection. SAM controls license of
number of user accounts.
Database Integrity: Built-in data encryption used for processing of sensi-
tive information such as: user passwords, PINs, etc
Number of Cards Supported: 20,478
Number of Access Groups: 255
Number of Time Schedules: 255
Intervals per Time Schedule: Four intervals per day, plus holidays support.
