Access Easy Controller 4-Reader Boards and 8 Input/8 Output Boards | en 103
Bosch Security Systems Hardware Manual Ver 2.0.0 | 2006.07
Connector T3 (second connector from top)
Pin# Function
1 Output #3 (common)
2 Output #3 (normally closed)
3 Output #3 (normally open)
4 Output #4 (common)
5 Output #4 (normally closed)
6 Output #4 (normally open
Connector T4 (third connector from top)
Pin# Function
1 Output #5 (common)
2 Output #5 (normally closed)
3 Output #5 (normally open)
4 Output #6 (common)
5 Output #6 (normally closed)
6 Output #6 (normally open)
Connector T5 (bottom connector)
Pin# Function
1 Output #7 (common)
2 Output #7 (normally closed)
3 Output #7 (normally open)
4 Output #8 (common)
5 Output #8 (normally closed)
6 Output #8 (normally open)
