Bosch Access Easy Controller User Manual

Access Easy Controller APPENDIX C Detail Wiring | en 195
Bosch Security Systems Hardware Manual Ver 2.0.0 | 2006.07
Location Cable Type
AC Input to Circuit Breaker to Line Filter. 3-conductor, 2.5 sq mm PVC insulated.
Line Filter to Power Supply 3-conductor, 2.5 sq mm PVC insulated.
RJ45 to CMC, directly or via hub UTP Category 5 Cable
Power Supply to CPU Card (T2) Belden 9409 - 18AWG, 2-conductor,
unshielded
CPU T2 to Reader Boards, Battery and
Tamper Switch*
Belden 9409 - 18AWG, 2-conductor,
unshielded
Reader Board to Reader Board or I/O Card. 28AWG, 40-Way Ribbon Cable.

Bosch Access Easy Controller Specifications

General

Brand	Bosch
Model	Access Easy Controller
Category	IP Access Controllers
Language	English
