200 en | APPENDIX E Access Easy Controller
Ver 2.0.0 | 2006.07 Hardware Manual Bosch Security Systems
7. Click OK and you will goes to the screen to set the Baudrate, set it to to 115200bps, 8bit
data, 1 stop bit and no parity.
8. Click OK button to start the connection.
9. Once you have connected to the GMS Modem, you shouldn’t change the baudrate.
10. Type "AT+IPR=19200" and press the enter key. You should get an "OK" replay.
11. Now you will need to change your baudrate of the Hyperterminal to 19200.
12. Click this icon to disconnect the connection.
13. Click on the icon to change the Baudrate to 19200 and then click on the icon to
reconnect with the GSM modem again.
14. Type "AT" and follows by a return, if the GSM modem replies you "OK" then the configu-
ration is complete.
15. You will need to save the configuration into the non -volatile memory in the GSM modem.
16. Type "AT&W" and follows by a return, the GSM modem will reply you "OK".
17. Reboot the GSM modem and try connecting again to the GMS modem using the baudrate
19200.
i
NOTICE!
Once connected, you should check whether the connection is stable by typing "AT" follow by
enter, you should get an "OK" reply from the GMS modem.
If there is no reply or the reply is not "OK" but display some unknown character, then it is pos-
sible that the GSM Modem baudrate is incorrect. Change the baudrate and reconnect.
