Access Easy Controller Table of Contents | en 5
Bosch Security Systems Hardware Manual Ver 2.0.0 | 2006.07
16.2 Technical Overview of Secure/Communication Card 117
16.2.1 LED Indicators 121
17 18VAC Input Power Supply Card 122
17.1 18V AC Input Power Supply Card for Main Controller Unit 123
17.1.1 Technical Overview of 18VAC Input Power Supply Card 124
17.2 18VAC Power Supply Card for Access Easy Extension Unit 127
17.2.1 Technical Overview of 18VAC Input Power Supply Card for Access Easy Extension Unit 128
18 15V DC Input Power Supply Card 132
18.1 15V DC Input Power Supply Card for Main Controller Unit 132
18.1.1 Technical Overview of 15VDC Input Power Supply Card 133
18.2 15VDC Power Supply Card for Access Easy Extension Unit 137
18.2.1 Technical Overview of 15VDC Input Power Supply Card 138
19 Convertor Card 141
19.1 Connector Layout of Convertor Card 141
19.1.1 Technical Overview of Convertor Card 143
19.1.2 Jumper Setting 148
19.1.3 LED Indicators 151
20 Power Supply Requirement and Connection 152
20.1 Current Consumption 152
20.2 Connection in the Main Controller 153
20.3 Connection in the Access Easy Extension Unit 158
21 Card Reader Keypad Functions 161
21.1 Keypad Layout 161
21.1.1 Keypad Functions 161
21.2 Entry Operation 162
21.2.1 Using Card + PIN mode on a Keypad Reader 162
21.2.2 Using Keypad in the Enable Keypad Only Operation mode 162
21.2.3 Other Usage 163
21.2.4 Changing PIN code 164
21.2.5 Entry and Arm/Disarm Reader 165
22 Troubleshooting Network Connectivity Problems 168
23 Troubleshooting Login Problems 174
24 Frequently Asked Questions 177
24.1 General Questions 177
24.2 Controller Questions 179
24.3 Reader and Door Questions 180
24.4 Inputs and Outputs 182
24.5 Network Question 183
