D6412/D4412 Installation Guide
45349D
D6412/D4412
2.1.4 Battery Discharge/Recharge Schedule
Discharge Cycle
AC Off: Command centers indicate trouble. AC Fail report sent as programmed.
13.8 VDC: Charging Float Level
12.1 VDC: Low Battery trouble at command centers. Low Battery report as programmed.
10.2 VDC: Panel shuts down as voltage falls below 10.2 VDC
Recharge Cycle
AC On: Panel restarts, battery charging begins, AC restoral report sent as programmed, AC trouble clears from
command centers.
13.0 VDC: Battery restoral reports sent, battery trouble clears from command centers.
13.8 VDC: Battery float charged.
2.1.5 Minimum Operating Voltage
10.2 VDC
2.1.6 SDI Bus (Data)
12 VDC nominal. 1,000 ft. (305 m) of 22 AWG (0.8 mm) cable.
2.1.7 Telephone Connections
RJ31X or RJ38X jack can be interfaced with panel.
2.1.8 Environmental
Temperature: +32° to +122°F (0° to +50°C)
Relative Humidity: 5-85% at 86°F (30°C) non-condensing
2.1.9 Arming Stations
D625 VF Text Command Center
D623 LCD Text Command Center
D621 LED Command Center
Keyswitch
2.1.10 Compatible Enclosures
D2203 Universal Enclosure (included with panel), D8103 Universal Enclosure*, D8109 Fire Enclosure*, D8108A
Attack Resistant Enclosure*
*When ordering a compatible enclosure, order the D6412M (includes the mounting skirt and the D6412LC) or
the D4412M (includes the mounting skirt and the D4412LC). In addition, please order the CX4010 transformer.
2.1.11 Compatible Accessories
D621 LED Command Center
D623 Text Command Center, LCD Display
D625 Text Command Center, Vacuum Fluorescent Display
DX2010 (D9528) Point Expansion Module
DX3010 (D9529) Octo-Output Module
DX3020 (X7410i) Module (not investigated by UL)
DX4010 (D9533) Serial Output Module (not investigated by UL)
DX8010 Telephone Command Module (not investigated by UL)
DS RF3224 Premises RF Receiver
DS RF3332/3334 Keyfob (not investigated by UL)
DS RF3341 Keypad (not investigated by UL)
Programming Key (PK32)
