Page 1645349D © 2002 Radionics
D6412/D4412 Installation Guide
D6412/D4412
3.0 Installation
3.1 Before You Begin
This section contains a general installation procedure. It refers to other sections of the manual for detailed
instructions.
Radionics recommends you review this manual and the D6412/D4412 Program Entry Guide (P/N: 45351) before
you begin the installation to determine the hardware and wiring requirements for the features you want to use.
Have the following additional documents handy as you read through this manual:
D6412 Program Record Sheet (P/N: 45350) or D4412 Program Record Sheet (P/N: 50485)
User’s Guide (Text Command Center - P/N: 46841; LED Command Center - 46840). A condensed version of
the User’s Guide can be found in the D6412/D4412 Program Entry Guide (P/N: 45351).
The installation manual for each model of Command Center you intend to install.
Before you begin the installation of the panel, you should be familiar with keypad programming or the Remote
Account Manager (RAM IV).
3.2 Enclosure Options
The D2203 Enclosure is supplied with the standard D6412/D4412 Control/Communicator. To mount the D6412
in one of the Radionics enclosures listed on the next page, order the D6412M version (order the D4412M
version for the D4412). The ‘M’ version substitutes a D2202 Mounting Skirt for the D2203 enclosure. The skirt
allows installation in the alternative enclosures. The ‘M’ does not include a transformer. Order a CX4010
separately. Refer to Appendix A, Approved Applications Compliance Guide, to determine if your application
requires a specific enclosure.
D8103 Universal Enclosure (gray)
D8109 Fire Enclosure (red)
D8108A Attack Resistant Enclosure (gray)
3.3 Beginning the Installation
3.3.1 Mounting the Enclosure
Mount the enclosure in the desired location.
3.4 Premises Wiring
Run the necessary wiring throughout the premises and route the wires into the enclosure.
IMPORTANT
EMI (Electro Magnetic Interference) may cause problems: EMI may occur if you install the system or run
system wires near the following:
• Computer network system
• Electrical lines, fluorescent fixtures or telephone cabling
• Ham radio transmitter site
• Heavy machinery and motors
• High voltage electrical equipment or transformers
• PBX telephone system
• Public service (police, fire departments, etc.) using radio communications
• Radio station transmitter site, or other broadcast station equipment
• Welding shop
If you think that EMI may be a problem, use shielded cable. The drain wire for the shielded cable must have
continuity from the earth ground terminal on the panel to the end of the wire run. If continuity is not maintained,
the shielded cable may aggravate potential noise problems rather than eliminate them.
Connecting the drain wire to ground at any place other than the earth ground terminal may also produce
problems. If you cut the drain wire to install devices, be certain to splice it together. Carefully solder and tape all
splices.
