D6412/D4412 Installation Guide
D6412/D4412
15.0 Terminal Quick Reference
Term
Silkscreen
(below terminals)
Description
1,2 18 VAC 18 V, 22 VA; up to 50 ft. (15.3 m), #18 AWG (1.2 mm), Stranded.
3 Earth Ground Symbol Earth Ground.
4 Data, Grn (Green)
SDI data on Terminals 4 &5. Panel supports up to 1,000 ft. (305 m) of #22 AWG (0.8 mm) wire on these terminals (any
configuration).
5 Data, Yel (Yellow)
6,7 Aux Power 12 VDC (-)
Terminals 6-9 are Aux power. 600 mA. Include any programmable outputs (PO 1 to PO 4) not configured for alarm output.
PTC protected.
8,9 Aux Power 12 VDC (+)
JP3 Aux/Data (RYGB) 4-pin connector to Data bus and Aux power. Use to connect an installer keypad for keypad programming.
Red (Bat +) Battery (+) spade.
Black (Bat -) Battery (-) spade.
10 PO 4
Programmable Output, up to 500 mA (-). Include in Aux Power calculations for all except 'Alarm' output functions. PTC
protected.
11 PO 3
Programmable Output, up to 500 mA (-). Include in Aux Power calculations for all except 'Alarm' output functions. PTC
protected.
12 PO 2
Programmable Output. 500 mA (-). Include in Aux Power calculations for all except 'Alarm' output functions. Supervised for
Horn/Speaker alarm function. PTC protected.
13 Alrm + Alarm power. Up to 1,850 mA. PTC protected. Provides power for supervised siren driver (PO 2) and Alarm Output (PO 1).
14 PO 1, A Jumper sets PO 1 terminals A (14) and B (15) for 'dry' Form "A" contact or for Alarm Output.
15 PO 1, B
16 L-1 (+)
Positive terminal of powered loop. Supports up to 15 smoke detectors (see the D6412/D4412 Smoke Compatibility List,
P/N: 46928). PTC protected.
L-1 (-) Negative terminal of powered loop.
18 Com Common for Sensor Loop 2.
19 L-2
Sensor Loop 2 input. Wire length for Sensor Loops 2 to 8 are limited only by the resistance on the loop and potential EMI
problems. Resistance must be < 100 Ω with EOL resistor shorted and detection devices connected.
20 L-3 Sensor Loop 3 input.
21 Com Common for Sensor Loops 3 and 4.
22 L-4 Sensor Loop 4 input.
23 L-5 Sensor Loop 5 input.
24 Com Common for Sensor Loops 5 and 6.
25 L-6 Sensor Loop 6 input.
26 L-7 Sensor Loop 7 input.
27 Com Common for Sensor Loops 7 and 8.
28 L-8 Sensor Loop 8 input.
29 T Tip of telephone line.
30 T1 Tip of house (premises) phones.
31 R1 Ring of house (premises) phones.
32 R Ring of telephone line.
JP2, PO1 Select æ Configures PO 1 for Form "A" relay or Alarm Output.
Auxiliary Auxiliary Module and/or Programming Key Header.
Installer Installer Jumper. Jumper required for keypad programming.
