Page 6645349D © 2002 Radionics
D6412/D4412 Installation Guide
D6412/D4412
16.1.3 Command Center Issues
Problem Cause Solution
I entered Cmd 50 at my command
center, but it will not let me move
to specific areas.
Cmd 50 (Move to Area) is
disabled if there are no points
assigned to a particular area.
Program at least one point and assign it to the
particular area. Cmd 50 should work as defined.
16.1.4 Programming Issues
Problem Cause Solution
I cannot enter into
programmer’s mode.
One or more areas are armed;
keypad programming may be
disabled; the Installer’s Switch
may be open.
−
If one or more areas are armed, disarm all
armed areas. Programmer’s mode cannot be
entered while one or more areas are armed.
However, an Installer’s Keypad can access
the programming mode regardless of the
panel’s arming state.
−
Programming may be disabled. See Section
2.5
Programming Options
,
Installer Switch
and Daylight Savings Time Options
(Nibble
0257) in the
D6412/D4412 Program Entry
Guide
(P/N: 45351). Make sure the following
options are enabled: Installer Switch, Keypad
Programming and PK32 (Programming Key).
−
To enter the programmer’s mode, the
Installer Switch must be closed. See the
following section in this installation guide for
details: 3.5.2,
Closing the Installer Switch,
and 13.2,
Entering the Installer Mode
.
I have enabled Open/Close
reports, but when I arm the
panel Part On, these
reports are still not sent.
The Open/Close reports for
Part On modes is not
programmed correctly.
In the
D6412/D4412 Program Entry Guide
(P/N:
45351), Section 2.7
Areas
, see the
Area #
Opening/Closing Reporting Options
parameter.
Enable “Opening/Closing Reports for Part On
Modes” for Nibbles 0296, 0318, 0340 and 0362.
The PK32 (Programming
Key) does not work
(upload, download, erase,
etc.).
The PK32 has not been
enabled in the panel firmware.
In Nibble 0257, enable the PK32. See the
D6412/D4412 Program Entry Guide
(P/N: 45351),
Section 2.5
Programming Options.
The off-board points I
added to the system
display as missing.
The device location parameter
is not correctly programmed.
See Section 2.13
Locations
in the
D6412/D4412
Program Entry Guide
(P/N: 45351)
.
Verify which
device type has been added (for example, RF
point, off-board point, etc.). In the Device Location
parameter, enter in the correct value based on the
Device Parameter Selections (1 = on-board; 2 =
DX2010; 3 = DX2010, Doubled; 4 = RF Receiver
1; 5 = RF Receiver 2). Point configuration is
locked into only those configuration types in the
Device Parameter Selections.
The panel is not following
report routing as
programmed.
The Lock Area Reporting
parameter is enabled.
Set the Lock Area Reporting parameter to 0
(Disabled). See the
D6412/D4412 Program Entry
Guide
(P/N: 45351) for more information.
16.1.5 Miscellaneous Issues
Problem Cause Solution
There are numbers in brackets [###]
throughout the
D6412/D4412
Program Entry Guide
(P/N: 45351).
These numbers [###] refer to the
event numbers described in Appendix
B of the
D6412/D4412 Program Entry
Guide
(P/N: 45351).
N/A
My printer is printing strange
characters and I cannot read it.
The settings for the DX4010 RS-232
Serial Interface Module will cause
unexpected printer output.
In the
D6412/D4412 Program Entry Guide
(P/N: 45351), see Section 2.19
SDI Bus
Device Configuration
. Verify the settings for
Nibbles 1253, 1254, and 1255.
