D6412/D4412 Installation Guide
D6412/D4412
2.3.8 EMI/Lightning Transient Protection
The panel maintains Radionics’ high level of quality and field dependability. Its design significantly reduces
electromagnetic interference and malfunction generally caused by lightning.
2.3.9 Programming
Use either a text keypad or the Remote Account Manager (RAM IV) to program the panel. Refer to the D6412/
D4412 Program Entry Guide (P/N: 45351) for programming options.
2.3.10 Other Features
• The panel has many programmable features. A short list of some of the features follows. Complete details on
all the features can be found in the D6412/D4412 Program Entry Guide (P/N: 45351).
• Supervision of AC (primary power), battery (secondary power), SDI bus devices (keypads, point expanders,
programmable output modules, alternate communication modules, etc.), CPU (Central Processing Unit), and
the telephone line (voltage only).
• Automatic system test reports
• Remote access for programming, diagnostics, and log uploads using the Remote Account Manager (RAM IV)
• Fire Alarm Verification
• Up to 20 (D6412) or 12 (D4412) Programmable Outputs, including a supervised siren driver
• Skeds (scheduled events)
2.3.11 Control/Communicator Assembly
The Radionics Control/Communicator is shipped pre-assembled from the factory. You should receive the
following parts with your panel.
Literature Pack
D6412 Control/Communicator
D6412/D4412 Installation Guide (P/N: 45349)
D6412 Program Record Sheet (P/N: 45350)
D6412/D4412 Program Entry Guide (P/N: 45351)
D6412 Release Notes (P/N: 46929)
D6412/D4412 Smoke Detector Compatibility Technogram (P/N: 46928)
D4412 Control/Communicator
D6412/D4412 Installation Guide (P/N: 45349)
D4412 Program Record Sheet (P/N: 50485)
D6412/D4412 Program Entry Guide (P/N: 45351)
D4412 Release Notes (P/N: 50482)
D6412/D4412 Smoke Detector Compatibility Technogram (P/N: 46928)
Assembly
• Printed Circuit Board (PCB)
• CX4010 Transformer (Order separately when ordering the D6412LC, D4412LC, D6412LT, D4412LT, D6412M,
or D4412M)
• Two Mounting Clips
• Two #6 x 3/4" screws
• Eight 2.2 k Ω end-of-line resistors (8-pack P/N: 47819, single resistor P/N: 25944B)
• Eight 3.65 k Ω point-doubling end-of-line resistors (8-pack P/N: 47821, single resistor P/N: 38130B)
• One 2.21 k Ω fire end-of-line resistor (P/N: 25899)
• Two 14", 18 AWG (1.2 mm), color-coded battery leads
• Three PCB support standoffs (P/N: 30503B)
