D6412/D4412 Installation Guide
D6412/D4412
2.1.12 Control/Communicator Configurations
D6412 - Complete Control/Communicator assembly in the D2203 Universal Enclosure. A CX4010 Transformer
is supplied.
D6412LT - Complete Control/Communicator assembly in the D2203 Universal Enclosure. A CX4010
Transformer must be ordered separately.
D6412LC - Complete Control/Communicator assembly without an enclosure or transformer. A CX4010
Transformer must be ordered separately.
D6412M - Complete Control/Communicator assembly with a mounting skirt for the compatible enclosure. A
CX4010 Transformer must be ordered separately. See Section 2.1.10 for compatible enclosure alternatives.
D4412 - Complete Control/Communicator assembly in the D2203 Universal Enclosure. A CX4010 Transformer
is supplied.
D4412LT - Complete Control/Communicator assembly in the D2203 Universal Enclosure. A CX4010
Transformer must be ordered separately.
D4412LC - Complete Control/Communicator assembly without an enclosure or transformer. A CX4010
Transformer must be ordered separately.
D4412M - Complete Control/Communicator assembly with a mounting skirt for the compatible enclosure. A
CX4010 Transformer must be ordered separately. See Section 2.1.10 for compatible enclosure alternatives.
2.2 SIA Control Panel Standard
The D6412/D4412 utilizes features within the SIA Control Panel Standard, Features for False Alarm Reduction,
SIA CP-01-1994.02 (R2000.01). SIA features are noted in the D6412/D4412 Program Entry Guide (P/N: 45351).
The standard is available through the Security Industry Association (SIA), 635 Slaters Lane, Suite 110,
Alexandria, Virginia 22314. You can e-mail requests for standards to: Standards@SIAOnline.org.
2.3 Standard Features
2.3.1 Points
Radionics’ D6412 Control/Communicator panel provides up to 40 separate points of protection (24 for the
D4412 panel). Point programming parameters determine the panel’s response to open and shorted conditions
on the point’s sensor loop. Points are programmed individually with several options to customize the protection
to your installation.
There are eight sensor loops available on the panel (for ‘on-board’ points). Off-board point locations can be
standard wired sensor loops (DX2010 Point Expander) or premises RF transmitters (premises RF receiver is
required).
The 40 points of protection for the D6412 (24 points for the D4412) can be located on any combination of wired
and RF locations.
2.3.2 Areas and Accounts
The system supports up to four separate areas for the D6412 and up to two separate areas for the D4412. You
can assign all points to a single area or spread them out over a maximum of two or four areas, model
dependent.
You arm and disarm the panel by area. You can arm and disarm several areas with one function. You can also
assign a passcode an authority level that allows a user to arm an area from a remote command center in
another area. Assigning each area its own account number creates four (D6412) or two (D4412) separate
accounts in one panel. Assigning the same account number to different areas, groups them together in a single
account.
Area options include: exit tone and delay, separate fire and burglary outputs, and auto opening and closing
skeds. Area 1 can be programmed as a ‘common’ area. A ‘First to Open, Last to Close’ arming feature is
available.
