Braking resistor
Integrated braking resistor data
Description Symbol Unit
KMV03.1R-
A05K0-P-D7-
ET-NNNN
KMV03.1R-
B0007-P-D7-
ET-NNNN
KMV03.1R-
I01K5-P-D7-
ET-NNNN
KMV03.1R-
W06K0-P-D7-
ET-NNNN
Braking resistor continuous power
P
BD
kW 0.15
Braking resistor peak power
P
BS
kW 12.00
Nominal braking resistance
R
DC_Bleede
r
ohm 60
Braking resistor switch-on
threshold - independent of mains
voltage
1)
U
R_DC_On_f
V 820
Regenerative power to be
absorbed
W
R_max
kWs 7.50
Cooling of integrated braking
resistor
Heat sink Base plate (Coldplate) Heat sink
Latest amendment: 2019-08-08
1) Factory setting
Tab. 5-15: KMV - Integrated braking resistor data
100/407
Technical data of the components
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
