5.9.2 RKH hybrid cable without communication, technical data
Data sheet - bulk cable
Description Symbol Unit REH0803
Brief description of cable (5 × 2.5 mm² + 5 × 0.34 mm²)StC
Operational voltage at power cores
U
0
/U
V 1000
Operational voltage at control cores
U
0
/U
V 100
Insulation resistance at 500 V DC
R
is
MΩ × km 500
Ambient temperature for operation (flexible
routing)
°C -20 … +80
Ambient temperature for operation
(permanent routing)
°C -30 … +80
Operating temperature at conductor (flexible/
permanent)
°C +80/+90
Ambient temperature for storage °C -30 … +80
Cable jacket material
1)
PUR
Cable jacket color RAL2003
Wire insulation material PP
Conductor resistance at 20 °C (EN 60228;
class 6)
R
20
Ω/km 8 (2.5 mm²)
Diameter D mm 11.4 ±0.3
Specific cable weight m kg/m 0.234
Application in flexible cable tracks Yes
Bending cycles
5 × 10
6
Bending radius with flexible routing mm 8 × D
Bending radius with permanent routing mm 4 × D
Bending and torsional stress °/m not suitable
Max. horizontal travel distance
2)
s m 50
Maximum travel velocity
3)
v m/s 5
Maximum acceleration
4)
a
max
m/s² 50 (5 m)
UL approval
5)
cURus
UL AWM Style AWM21223
RoHS (EU) compliant with Directive 2011/65/EC
Halogens halogen-free according to VDE 0472, Part 815
Oil resistance HD22.10 S1 and VDE0282
Flammability
IEC 60332-1-2; UL 1581, Sec. 1061; UL 2556,
Sec. 9.3
Latest amendment: 2019-06-17
1) According to EN 50363-10-2
116/407
Technical data of the components
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
