1.3.3 KMS02 near motor servo drive
KMS02 type code
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: K M S 0 2 . 1 B - A 0 1 8 - P - D 7 - E T - E N H - L 3 - T O - F W
① ② ③④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬
① Product:
KMS = KMS
② Series:
02 = 2
③ Design:
1 = 1
④ Performance:
B = Basic
⑤ Cooling type:
A = Natural convection (exterior heat sink)
⑥ Maximum current:
018 = 18 A
⑦ Degree of protection:
P = IP65
⑧ Nominal DC bus voltage:
D7 = DC 750 V
⑨ Master communication:
ET = Multi-Ethernet
⑩ Encoder interface:
ENH = Encoder Hiperface®
NNN = Without
3) 4)
ENA = Encoder ACURO®link
3)
⑪ Safety option:
L3 = Safe Torque Off (STO)
S3 = Safe Motion (without SBC)
1) 3)
SD = Safe Motion
1)
NN = Without
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
17/407
System presentation
R911335703_Edition 04 Bosch Rexroth AG
