10.17 RKB0054, fan cable
1 BN 24 V
2 WH 0 V
3 BU n. c.
4 BK n. c.
Fig. 10-25: RKB0054
Assignment
For devices of the "W" cooling type (forced cooling).
Length that can be ordered, order
code, material number
Length Order code Material number
To be freely
selected
RKB0054/xxx,x (xxx,x = length in meters) R911378870
Tab. 10-24: RKB0054
330/407
Accessories
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
