Bosch rexroth IndraDrive Mi KMS03 User Manual

Motors
Title
Rexroth IndraDyn …
Type of documentation
Document typecode
1)
DOK-MOTOR*-…
Material number
R911…
A Asynchronous Motors MAD / MAF Project Planning Manual MAD/MAF****-PRxx-EN-P 295781
H Synchronous Kit Spindle Motors Project Planning Manual MBS-H******-PRxx-EN-P 297895
L Synchronous Linear Motors Project Planning Manual MLF********-PRxx-EN-P 293635
S Synchronous Servo Motors MSK Project Planning Manual MSK********-PRxx-EN-P 296289
T Synchronous Torque Motors Project Planning Manual MBT********-PRxx-EN-P 298798
1) In the document typecodes, "xx" is a placeholder for the current
edition of the documentation (e.g.: PR01 is the first edition of a
Project Planning Manual)
Tab. 1-18: Documentations – overview
Cables
Title Type of documentation
Document typecode
1)
DOK-…
Material number
R911…
Rexroth Connection Cables
IndraDrive and IndraDyn
Selection Data CONNEC-CABLE*INDRV-CAxx-
EN-P
322949
1) In the document typecodes, "xx" is a placeholder for the current
edition of the documentation (e.g.: CA02 is the second edition
of the "Selection Data" documentation)
Tab. 1-19: Documentations – overview
Firmware
Title Type of documentation
Document typecode
1)
DOK-INDRV*-…
Material number
R911…
IndraDrive
MPx-21
Functions
Application Manual MP*-21VRS**-APxx-EN-P 385758
IndraDrive
MPx-20
Functions
Application Manual MP*-20VRS**-APxx-EN-P 345608
IndraDrive
MPx-20
Version Notes
Release Notes MP*-20VRS**-RNxx-EN-P 345606
IndraDrive
Power Supply Basic PSB‑21
Functions
Application Manual PSB-21VRS**-APxx-EN-P 385754
IndraDrive
Power Supply Basic PSB‑21
Version Notes
Release Notes PSB-21VRS**-RNxx-EN-P 385752
28/407
System presentation
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
