5.9 RKH hybrid cable
5.9.1 RKH hybrid cable incl. communication, technical data
Data sheet - bulk cable
Description Symbol Unit REH0800
Brief description of cable
[5 × 2.5 mm² + 5 × 0.34 mm² + (2 × 2 × 0.34
mm²)StC]C
Operational voltage at power cores
U
0
/U
V 850
Operational voltage at control cores
U
0
/U
V 100
Insulation resistance at 500 V DC
R
is
MΩ × km 500
Ambient temperature for operation (flexible
routing)
°C -20 … +80
Ambient temperature for operation
(permanent routing)
°C -30 … +80
Operating temperature at conductor (flexible/
permanent)
°C +80
Ambient temperature for storage °C -30 … +80
Cable jacket material
1)
PUR
Cable jacket color RAL2003
Wire insulation material according to EN 13602 -CU-ETP-A…
Conductor resistance at 20 °C (EN 60228;
class 6)
R
20
Ω/km 8 (2.5 mm²)
Diameter D mm 16.2 ±0.5
Specific cable weight m kg/m 0.355
Application in flexible cable tracks ✓
Bending cycles
5 × 10
6
Bending radius with flexible routing mm 10 × D
Bending radius with permanent routing mm 5 × D
Bending and torsional stress °/m max. ±30
Max. horizontal travel distance
2)
s m 10
Maximum travel velocity
3)
v m/s 4
Maximum acceleration
4)
a
max
m/s² 4
UL approval
5)
cURus
UL AWM Style AWM20234
RoHS (EU) compliant with Directive 2002/95/EC
Halogens halogen-free according to VDE 0472, Part 815
Latest amendment: 2019-06-17
