1.3.5 KCU02 drive connection box
KCU02.2 type code
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: K C U 0 2 . 2 N - E T - E T * - 0 2 5 - N N - N - N N - N W
① ② ③④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪
① Product:
KCU = KCU
② Series:
02 = 2
③ Design:
2 = 2
④ Configuration option:
N = Fixed configuration
⑤ Master communication (input):
ET = Multi-Ethernet
⑥ Master communication (output):
ET* = Multi-Ethernet
⑦ DC fuse:
025 = Nominal current: 25 A
⑧ Interface:
NN = None
⑨ Control panel:
N = Without
⑩ Other design:
NN = None
⑪ Firmware:
NW = Without firmware
Tab. 1-11: Type code KCU02.2
KCU02.2 vs. KCU02.1
KCU02.2 is fully downward compatible with version KCU02.1 and completely
replaces this type.
20/407
System presentation
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
