8 Identification
8.1 Scope of supply
8.1.1 KCU02
Standard Optional
● KCU02
● Documentation
● HAS01.1-050 connection and mounting accessory
● HAS02.1-015 accessory for shield connection
● HAS03 mounting accessory
● RKB0021 long Multi-Ethernet cable
● RKB0013 short Multi-Ethernet cable
Tab. 8-1: Scope of supply
8.1.2 KSM02/KMS02
Standard Optional
● KSM02
or
● KMS02
● Documentation
● System type plate
● RBS0023
Connector for safety zone node
● RKB0033
Safety technology cable (X141 ↔ external safety
unit)
● RKB0043
Cable for communication (M12-D ↔ M12-D)
● RKB0044
Cable for communication (M12-D ↔ RJ-45)
● RKS0010
Interface cable (M12-A ↔ open ends)
● HAS10
Fixing clip for hybrid cables
Tab. 8-2: Scope of supply
