5.7 KNK03 mains filter
5.7.1 KNK03 data sheet
Technical data - currents, voltages, power
Description Symbol Unit
KNK03.1A-
NR-A0008-P-
U226-A4-
NNNN
KNK03.1A-
NR-B0012-P-
U226-A4-
NNNN
KNK03.1A-
NR-I0002-P-
U226-A4-
NNNN
KNK03.1A-
NR-W0010-P-
U226-A4-
NNNN
Degree of protection according to
IEC 60529
IP IP65
Listing in accordance with UL
standard
UL 61800-5-1
Listing in accordance with CSA
standard
CSA C22.2 No. 274-13
Mass m kg 24.00 20.00 24.00
Three-phase mains voltage at TN-
S, TN-C, TT mains
U
LN
V AC 380…500
Mains voltage, three-phase at IT
mains
2)
U
LN
V AC 380…500
Mains voltage, three-phase at
Corner-grounded-Delta mains
U
LN
V Not allowed
Tolerance rated input voltage U
LN
% ±10
Mains input contin. current
I
L_cont
A 8.1 12 2.3 9.5
Typical inductance per winding at
I
cont
L
typ
µH 2.3
Power dissipation at continuous
current and continuous DC bus
power respectively
3)
P
Diss_cont
W 147 175 104 160
Allowed leakage capacitance
C
Abl
nF 226
Allowed Y-capacitance
C
Y
nF 2200
Insulation resistance at 500 V DC
R
is
Mohm > 1
Required wire size in accordance
with NFPA 79 and UL 508 A
(internal wiring);
4)
A
LN
AWG 14
Latest amendment: 2019-08-08*
1) 2) Mains voltage > U
LN
: Use a transformer with grounded neutral
point, do not use autotransformers!
3) Plus dissipation of braking resistor and control section
4) Copper wire; PVC-insulation (conductor temperature 90 °C;
T
a
≤ 40 °C) in accordance with NFPA 79 chapter 12 and
UL 508A chapter 28
Tab. 5-17: KNK - Technical data - currents, voltages, power
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
105/407
Technical data of the components
R911335703_Edition 04 Bosch Rexroth AG
