6.5.2 Motor cable and encoder cable connection
Condition as supplied
1 Connection cover
2 Protective covering
3 Screws (M4, 2.5 Nm)
Fig. 6-14: Connection cover with protective covering
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
187/407
Connection points
R911335703_Edition 04 Bosch Rexroth AG
