RKH0012
RKH0211
RKH0611
RKH0111
RKH0213
RKH0215
Locking pin
Coding profile
2)
1) Picture shows coding with view to mating side
2) The coding profile ensures the downward compatibility of the
hybrid cable for KSM01/KMS01
Tab. 5-26: Parts of ready-made hybrid cables from KSM/KMS to KSM/KMS
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
125/407
Technical data of the components
R911335703_Edition 04 Bosch Rexroth AG
