Circular connector
RHS2321 RHS2322
M23, female, Ø: 28 mm
M23, male, Ø: 28 mm
Tab. 5-32: Circular connector
Housing duct
For RKH09xx hybrid cables, a metallic flange can be fitted to the circular
connector.
This allows hybrid cable housing ducts to be implemented with a pluggable
connection at the housing (control cabinet, machine).
See chapter 10.24 "Metallic flange for circular connectors" on page 337.
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
131/407
Technical data of the components
R911335703_Edition 04 Bosch Rexroth AG
