Time behavior
Description Unit min. max.
Test pulse width (t
PL
) μs 100 200
Periodic time (T
P
) ms 500 1000
Phase shift between two test pulses on both channels
(φ)
ms 50 -
Tab. 14-7: Time behavior
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
373/407
Appendix
R911335703_Edition 04 Bosch Rexroth AG
