Hybrid cable damping factor
Mains filter k
HNF01.2D-F0240-Rxx 1.20
HNF01.2D-F0240-Exx 0.72
HNF01.2D-M900-Rxx 0.80
HNF01.2D-M900-Exx 0.61
HNF01.1A-H350-Rxx 1.00
NFD03.1 1.15
NFE02.1
1)
-
KNK03.1 1.00
1) Cannot be used with IndraDrive Mi
Tab. 14-11: Hybrid cable damping factor
C
leak_sum
C
leak_sum
= C
leak_cable_Hxx
+ C
leak_motor_Hxx
+ C
leak_cable_KMS
+ C
leak_motor_KMS
+ C
leak_motor_KSM
C
leak_sum
: Sum of leakage capacitances
C
leak_cable_Hxx
: Sum of leakage capacitance, standard motor power cable by Rexroth at
HMS/HMD or HCS
C
leak_motor_Hxx
: Sum of leakage capacitance, MSK motor by Rexroth at HMS/HMD or HCS
C
leak_cable_KMS
: Sum of leakage capacitance, standard motor power cable by Rexroth at KMS
C
leak_motor_KMS
: Sum of leakage capacitance, MSK motor by Rexroth at KMS
C
leak_motor_KSM
: Sum of leakage capacitance, KSM
Tab. 14-12: C
leak_sum
IndraDrive Mi capacitances
Component C
Y
[nF] C
leak_motor_KSM
[nF]
KSM02.1B-041C-42 150 1.4
KSM02.1B-061C-35 150 2.4
KSM02.1B-061C-61 150 2.2
KSM02.1B-071C-24 150 5.0
KSM02.1B-071C-35 150 4.7
KSM02.1B-076C-35 150 6.9
KMS02.1B-A018 218 -
KMS03.1B-A036 200 -
KMS03.1B-B036 200 -
KCU02.1N 200 -
KCU02.2N 200 -
KMV03 350 -
Tab. 14-13: IndraDrive Mi capacitances
