Component C
Y
[nF]
HMD01.1N-W0020 136
HMD01.1N-W0036 136
Tab. 14-15: IndraDrive M capacitances
Cables, capacitances
Cable C
leak_cable
[nF/m]
INK653 (1.0 mm
2
)
0.6
INK650 (1.5 mm
2
)
0.8
INK602 (2.5 mm
2
)
0.7
INK603 (4.0 mm
2
)
0.8
INK604 (6.0 mm
2
)
0.8
INK605 (10.0 mm
2
)
1.0
INK606 (16.0 mm
2
)
1.2
INK607 (25.0 mm
2
)
1.1
INK667 (35.0 mm
2
)
1.2
INK668 (50.0 mm
2
)
1.3
REL0105 (1.0 mm
2
)
0.4
REL0753 (1.0 mm
2
)
0.4
REL0106 (1.5 mm
2
)
0.4
REL0107 (2.5 mm
2
)
0.4
REL0108 (4.0 mm
2
)
0.5
REL0109 (6.0 mm
2
)
0.5
REL0110 (10.0 mm
2
)
0.5
REL0111 (16.0 mm
2
)
0.6
REL0112 (25.0 mm
2
)
0.6
REL0113 (35.0 mm
2
)
0.6
REH0804 (1.5 mm
2
)
0.4
Tab. 14-16: Cables, capacitances
Motor, capacitances
Motor C
leak_motor
[nF]
MAD100B-0050 6.0
MAD100B-0100 5.7
MAD100B-0150 5.7
MAD100B-0200 6.0
MAD100B-0250 6.0
