Motor C
leak_motor
[nF]
MS2N10-C0BNN 2.0
MS2N10-D0BHN 3.2
MS2N10-D0BNN 4.1
MS2N10-E0BNN 6.2
MS2N10-E1BNN 5.0
MS2N10-F0BHN 8.7
MS2N10-C0BNA 2.0
MS2N10-C0BNB 2.0
MS2N10-D0BHA 3.2
MS2N10-D0BHB 3.2
MS2N10-D0BNA 4.1
MS2N10-D0BNB 4.1
MS2N10-D1BNA 3.3
MS2N10-D1BNB 3.3
MS2N10-E0BHA 6.2
MS2N10-E0BHB 6.2
MS2N10-E0BNA 6.2
MS2N10-E0BNB 6.2
MS2N10-E1BNA 5.0
MS2N10-E1BNB 5.0
MS2N10-F0BHA 8.7
MS2N10-F0BHB 8.7
MS2N10-F1BHA 6.7
MS2N10-F1BHB 6.7
Tab. 14-17: Motor, capacitances
