Risk of damage to the DC bus capacitor unit
KLC from long-term storage!
NOTICE
The DC bus capacitor unit KLC contains electrolytic capacitors which may
deteriorate during storage. When storing the DC bus capacitor unit KLC for a
longer period of time, run it once a year for at least 1 hour at DC bus voltage
U
DC
.
Ambient and operating conditions - storage
Description Symbol Unit Value
Temperature range T
a_store
°C -20 … +55
Relative humidity % 5 … 95
Absolute humidity
g/m
3
1 … 29
Climatic category (IEC721) 1K3
Moisture condensation Not allowed
Icing Not allowed
Tab. 4-5: Ambient and operating conditions - storage
KSM: Storage times
Additional measures must be taken on commissioning to preserve proper
functioning – irrespective of the storage time which may be longer than the
warranty period of our products. However, this does not involve any
additional warranty claims.
Motors
Storage time / months
Measures for commissioning
> 1 > 12 > 60
■ ■ ■ Visual inspection of all parts to be damage-free
■ ■ ■ Resurface the holding brake
■ ■
Check the electric contacts to verify that they are free from
corrosion
■ ■ Let the motor run in without load for one hour at 800 ... 1000 rpm
■ ■
Measure insulation resistance. Dry the winding at a value of <
1kohm per volt rated voltage.
■ Replace bearing
■ Replace encoder
Tab. 4-6: Measures before commissioning motors that have been stored over
a prolonged period of time
48/407
General data and specifications
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
