Bowa ARC 400 - Technical Specifications; ARC 400 Technical Data (REF 900-400)

10 Technical specifications
BOWA-IFU-11779-ARC400-V2.1.0-S0-EN Operating Manual ARC 400 111
10. Technical specifications
10.1. ARC 400 technical data (REF 900-400)
Insulation type / Classification
EMC
IEC 60601-1-2
Level of protection provided by the housing
IP 21
Protection class according to EN 60601-1
I
Application component type according to EN 60601-1
CF
Standards compliance
IEC 60601-1: 2005,
IEC 60601-1-2:2007,
IEC 60601-2-2: 2009,
ISO 14971: 2007
ISO 13485: 2003 + Cor.1 2009
Classification according to EC Directive 93/42/EEC
IIb
Power connection
220 V - 240 V
100 V - 127 V
Min. Power consumption
3 W / 40 VA
3 W / 40 VA
Min. Current consumption
200 mA
400 mA
Max. power consumption (at 400 W)
700 W / 1150 VA
700 W / 1150 VA
Max. current consumption (at 400 W)
5 A
10 A @ 100 V
8 A @ 127 V
Line fuses
2 x T 5 AH 250 V
2 x T 10 AH 250 V
Mains frequency
50 / 60 Hz
50 / 60 Hz
Terminal for potential equalization


Dimensions and weight
Dimensions
430 x 180 x 475 mm
Net weight
12,5 kg
Packaging information /dimensions
Carton 685 x 497 x 280 mm
Gross weight
18 kg
Programs
Number of programs in the device
300
Default programs, factory set
Yes
Individually programmable
Yes
Information shown on the display
Yes
